PY103 Diferential Pressure Transmitter

PY 103 diﬀerential pressure transmitter is a diﬀerential pressure sensitive element encapsulated in a stainless steel all-welded structure housing with G1/4 female threads for both positive and negative chamber pressure connections.
It can be mounted on the measuring pipe through the G1/4 female thread pressure interface or connected through the pilot tube, using the cable lead way.
Widely used in industrial process control, ﬂow measurement, medical instrumentation, aerodynamic measurement, hydraulic and pneumatic equipment and other ﬁelds.

Applications:

■ Refrigerating System
■ Hydraulic Pressure & Pneumatic Device
■ Measurement & Control
■ Mechanical Equipment
■ Pump & Compressor
■ Pharmaceutic

Product Features:
■ Measuring ranges : 0 …35 bar
■ Accuracy: up to 0.2 % F.S
■ Full solid-state isolation
■ Resistant to static pressure up to 200bar
■ Standard G1/4 female thread interface
■ Suitable for diﬀerential pressure measurement of liquids, gases and other media

■ Pressure ranges: -0.1 ... 2,500 bar

■ Accuracy: 0.2%FS , 0.25 % FS , 0.5 % FS

■ Start-up time: 2 seconds, no need to warm up

■ Long-term stability ±0.8: F.S/year

■ Temperature coeﬃcient: 0.3% /10℃ (within -40~85℃, the zero point and the range combined)

■ Power supply: 10~36VDC

■ Analog output: 4〜20mA DC (Load resistance ≤750Ω ) , 0〜10 mA DC (Load resistance ≤1.5KΩ ), 1〜5V DC (Load resistance ≥250K ) , 0〜5V DC (Load resistance ≥250K )

■ Overpressure: 5bar or 3×FS, whichever is smaller

■ Electrical connection: Hirschmann connector, waterproof connector optional

■ Thread: 1/4NPT, 1/2NPT, G1/2, G1/4,Others can be customized

■ Material: 304

■ Ambient conditions: -20...70°C with air humidity ≤95%r.h.

■ Weight: 250 g

PY103 diﬀerential pressure transmitter
